PERFORMANCE
| Processor | AMD Ryzen™ 7 7745HX (8C / 16T, 3.6 / 5.1GHz, 8MB L2 / 32MB L3) |
|---|---|
| Graphics | NVIDIA GeForce RTX™ 4070 8GB GDDR6, Boost Clock 2175MHz, TGP 140W |
| Chipset | AMD SoC Platform |
| Memory | 2x 16GB SODIMM DDR5-5200 |
| Memory Slots | Two DDR5 SODIMM slots, dual-channel capable |
| Max Memory | Up to 32GB DDR5-5200 offering |
| Storage | 1TB SSD M.2 2280 PCIe® 4.0x4 NVMe® |
| Storage Slot | Two M.2 2280 PCIe® 4.0 x4 slots |
| Max Storage Support | Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 1TB |
| Optical | None |
| Card Reader | No Card Reader |
| Audio Chip | High Definition (HD) Audio, Realtek® ALC3306 codec |
| Speakers | Stereo speakers, 2W x2, optimized with Nahimic Audio |
| Microphone | 2x, Array |
| Camera | FHD 1080p with E-shutter |
| Battery | 80Wh |
| Power Adapter | 300W Slim Tip (3-pin) |
| Special Features | Legion Coldfront 5.0 cooling system |
DESIGN
| Display | 16" WQXGA (2560x1600) IPS 500nits Anti-glare, 100% sRGB, 240Hz, DisplayHDR™ 400, Dolby Vision®, FreeSync™, G-SYNC®, Low Blue Light, High Gaming Performance |
|---|---|
| Touchscreen | None |
| Color Calibration | Factory Color Calibration |
| Pen | Pen Not Supported |
| Keyboard | 4-Zone RGB Backlit, English |
| Touchpad | Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches) |
| Dimensions (WxDxH) | 363.4 x 260.35 x 22.45-26.75 mm (14.31 x 10.25 x 0.88-1.05 inches) |
| Weight | Less than 2.5 kg (5.5 lbs) |
| Case Color | Onyx Grey |
| Case Material | Aluminium (Top), PC-ABS (Bottom) |
| Surface Treatment | Anodizing |
SOFTWARE
| Operating System | None |
|---|---|
| Bundled Software | None |
CONNECTIVITY
| WLAN + Bluetooth | Wi-Fi® 6, 802.11ax 2x2 + BT5.2 |
|---|---|
| WWAN | WWAN Not Supported |
| Ethernet | 100/1000M (RJ-45) |
| Standard Ports | 1x USB 3.2 Gen 1 (Always On) ; 3x USB 3.2 Gen 1 ; 1x USB-C® 3.2 Gen 2 (support data transfer and DisplayPort™ 1.4) ; 1x USB-C® 3.2 Gen 2 (support data transfer, Lenovo® Power Delivery 140W and DisplayPort™ 1.4) ; 1x HDMI® 2.1, up to 8K/60Hz ; 1x Headphone / microphone combo jack (3.5mm) ; 1x Etherne |
SECURITY & PRIVACY
| Security Chip | Firmware TPM 2.0 Enabled |
|---|---|
| Fingerprint Reader | No Fingerprint Reader |
| Other Security | E-shutter |
SERVICE
| Base Warranty | 2-year, Courier or Carry-in with 1-year Battery |
|---|---|
| Included Upgrade | 2Y Premium Care with OnSite from 2Y Depot (CPN) |
ACCESSORIES
| Bundled Accessories | None |
|---|
CERTIFICATIONS
| Green Certifications | ErP Lot 3 ; RoHS compliant |
|---|---|
| Other Certifications | TÜV Rheinland® High Gaming Performance ; TÜV Rheinland® Low Blue Light (Hardware Solution) |
